Polymer Sorting
GVR Series Plastic Color Sorter Machine
GVR Series Plastic Color Sorter Machine utilizes advanced visible light technology to deliver exceptional color separation and purification for various plastic materials, including PET flakes, HDPE, PP and other polymer flakes. This machine is engineered to enhance the quality and value of recycled plastics by ensuring precise sorting and removal of contaminants.
|
Model
|
Capacity(T/H)
|
Voltage (V/Hz)
|
Power (KW)
|
Dimensions(MM)
|
|---|---|---|---|---|
|
IR Pro-4
|
1.5-3
|
240V/50
|
4.2
|
2150*1928*2385
|
|
IR Pro-5
|
2-4
|
240V/50
|
4.4
|
2825*1928*2385
|
|
IR Pro-6
|
2.8-5.6
|
240V/50
|
5.2
|
2825*1928*2385
|
|
IR Pro-7
|
3-6
|
240V/50
|
5.9
|
3518*1928*2385
|
|
IR Pro-8
|
4-8
|
240V/50
|
7.3
|
3518*1928*2385
|
* The above parameters will vary according to the impurity of raw material & may change due to technological improvement.
Key Features
High-resolution sensors accurately differentiate even minor color variations for precise sorting.
Offers multiple sorting options, including normal, reverse, single, re-sorting and multi-stage sorting for greater adaptability.
Engineered for fast, continuous operation, ensuring high throughput with minimal manual intervention.
AI-powered algorithms achieve 99.8% accuracy, reducing waste and improving material purity.
Advantages
Effectively removes unwanted colors, contaminants and impurities, ensuring high-grade recycled plastics.
Designed for long-term, unmanned operations, reducing labor costs and increasing productivity.
An optimized sorting system reduces power consumption while maintaining peak performance.
Handles PET, HDPE, PP and mixed plastic flakes, ensuring versatile application in the recycling industry.
