Belt Type Color Sorter
Belt Type Color Sorter
The Belt Type Color Sorter Machine is an advanced optical sorting solution designed for high-precision separation of materials based on color differences. Utilizing a conveyor belt feeding system, this machine is particularly effective for fragile, irregularly shaped or larger-sized products that require gentle handling. The system combines high-resolution cameras, specialized lighting and intelligent software to detect and eject defective particles with exceptional accuracy.
|
Model
|
Throughput (T/H)
|
Accuracy (%)
|
Voltage (V/Hz)
|
Power (KW)
|
Weight (Kg)
|
Dimension (mm)
|
|---|---|---|---|---|---|---|
|
LG1 (KP+Hi)
|
0.5-1
|
>=99%
|
380/50
|
2.5
|
860
|
3273*1110*1786
|
|
LG2 (KP) / LG2 (KP+Hi)
|
0.5-1.5
|
>=99%
|
380/50
|
3.6
|
1000
|
3273*1410*1826
|
|
LG4 (KP) / LG4 (KP+Hi)
|
1-3
|
>=99%
|
380/50
|
4.4
|
1210
|
3403*2010*2087
|
|
Model
|
Throughput (T/H)
|
Accuracy (%)
|
Voltage (V/Hz)
|
Power (KW)
|
Weight (Kg)
|
Dimension (mm)
|
|---|---|---|---|---|---|---|
|
KNS - 2
|
1-2
|
>=99%
|
380/50
|
4.8
|
1360
|
3615*1410*2666
|
|
KNS - 4
|
1-3
|
>=99%
|
380/50
|
6.2
|
1686
|
3590*2010*2947
|
|
KNS - 6
|
2-4
|
>=99%
|
380/50
|
8.4
|
2140
|
3615*2610*3176
|
|
Model
|
Throughput (T/H)
|
Voltage (V/Hz)
|
Power (KW)
|
Dimension (MM)
|
|---|---|---|---|---|
|
KNS-2
|
1-2
|
380/50
|
4.8
|
3615*1410*2666
|
|
KNS-4
|
1-3
|
380/50
|
6.2
|
3590*2010*2947
|
|
KNS-6
|
2-4
|
380/50
|
8.4
|
3615*2610*3176
|
* The above parameters will vary according to the impurity of raw material & may change due to technological improvement.
Key Features
Gentle material handling is ideal for delicate products.
Multi-spectral imaging for precise defect detection.
Customizable processing speed for optimal sorting efficiency.
Easy-access components for maintenance and cleaning.
Optimized for cost-effective operation.
Advantages
Higher sorting accuracy for products with uneven surfaces or mixed sizes.
Minimizes product breakage due to gentle belt-based conveyance.
Increases processing efficiency with continuous feeding and sorting.
Reduces manual sorting labor and operational expenses.
